R110C25B| 3B Filters | Pleated Paper Element OFS # 97-01-3352

PLEATED PAPER ELEMENT Usually ships in 24-48 hours Usually Ships In 24-48 Hours

Performance Data
Micron Rating:  25.00 NOMINAL

Beta Rating:  N/A

Collapse Pressure Rating:  72 PSI

Maximum Temperature:  225 F

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  20 PSID

Dimensional Specifications
Outer Diameter, Top:  1.97 IN   (50.04 MM)

Outer Diameter, Bottom:  1.97 IN   (50.04 MM)

Inner Diameter, Top:  1.02 IN   (25.91 MM)

Inner Diameter, Bottom:

Length:  2.76 IN   (70.10 MM)

Thread:  NONE

Physical Specifications
Handle:  NONE

Seal Material:  BUNA-N

Type of Adhesive:

Type of Endcap:  PLATED STEEL

Center Tube:  PLATED STEEL

Type of Media:  PAPER

Filter Area:  74 SQ.IN.

Plating:  ELECTROTIN PLATED

Outer Jacket:  NONE

Configuration:  SINGLE OPEN END

Packaging Specifications
Number per Carton:  1

Carton Weight: ***All Online Filter Supply replacement products are equivalent to or interchangeable with original manufacture parts***
