R110T125B| 3B Filters | Pleated Wire Element | OFS # 97-06-0860

PLEATED WIRE ELEMENT

Performance Data
Micron Rating:  125.00 ABSOLUTE

Beta Rating:

Collapse Pressure Rating:  145 PSI

Maximum Temperature:  248 F

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  25 PSID

Dimensional Specifications
Outer Diameter, Top:  2.05 IN   (52.07 MM)

Outer Diameter, Bottom:  2.05 IN   (52.07 MM)

Inner Diameter, Top:  0.96 IN   (24.38 MM)

Inner Diameter, Bottom:

Length:  2.83 IN   (71.88 MM)

Thread:  N/A

Physical Specifications
Handle:  NONE

Seal Material:  BUNA-N

Type of Adhesive:

Type of Endcap:  PLATED STEEL

Center Tube:

Type of Media:  WIRE MESH

Filter Area:  36 SQ.IN.

Plating:

Outer Jacket:  NONE

Configuration:  SINGLE OPEN END

Packaging Specifications
Number per Carton:  1

Carton Weight: ***All Online Filter Supply replacement products are equivalent to or interchangeable with original manufacture parts***
