R120C25BG| 3B Filters | Pleated Paper Element | OFS # 97-01-3356
Performance Data
Micron Rating: 25.00 NOMINAL
Beta Rating:
Collapse Pressure Rating: 44 PSID
Maximum Temperature: 225 F
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Dimensional Specifications
Outer Diameter, Top: 2.76 IN (70.10 MM)
Outer Diameter, Bottom: 2.76 IN (70.10 MM)
Inner Diameter, Top: 1.16 IN (29.46 MM)
Inner Diameter, Bottom:
Length: 3.35 IN (85.09 MM)
Thread: NONE
Physical Specifications
Handle: NONE
Seal Material: BUNA-N
Type of Adhesive:
Type of Endcap: PLATED STEEL
Center Tube: PLATED STEEL
Type of Media: PAPER
Filter Area: 154 SQ.IN.
Plating:
Outer Jacket: NONE
Configuration: SINGLE OPEN END
Packaging Specifications
Number per Carton: 1
Carton Weight: ***All Online Filter Supply replacement products are equivalent to or interchangeable with original manufacture parts***
