0-451-103-004 | Bosch | Spin-On Filter Element
Description
OFS# 97-25-0349
Performance Data
Micron Rating: 25.00 NOMINAL
Beta Rating: N/A
Collapse Pressure Rating: 75 PSID
Maximum Tempeature: 225 F
Max Heat - 225 Ferihent
Direction of Flow: OUTSIDE->IN
Recommended Change-out Differential Pressure: 20 PSID
Dimensional Specifications
Outer Diameter, Top: 3.70 Inches (93.98 MM)
Outer Diameter, Bottom: 3.70 Inches (93.98 MM)
Inner Diameter, Top:
Inner Diameter, Bottom:
Length: 3.88 Inches (98.55 MM)
Thread: 3/4-16 UNF-2B
Physical Specifications
Handle: NONE
Seal Material: BUNA-N
Type of Adhesive: PLASTISOL
Adhesive Type - Plastisol
Type of End-cap: PLATED STEEL
End cap Type - Plated Steal
Center Tube: PLATED STEEL
Type of Media: PAPER
Media Type - Paper
Filter Area: SQ.IN.
Plating: ELECTROTIN PLATED
Outer Jacket: YES - METAL
Jacket Outer -
Configuration: SINGLE OPEN END
Packaging Specifications
Number per Carton: 12
Carton Weight: 13.30 LB ( Please contact for availability of broken cases)
