FF2 | Luber-Finer | Spin-On Element | OFS # 97-25-0372
Performance Data
Micron Rating: 10.00
Beta Rating: N/A
Collapse Pressure Rating:
Maximum Temperature:
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Additional Notes: 50 PSI MAXIMUM WORKING PRESSURE
Dimensional Specifications
Outer Diameter, Top: 3.81 IN (96.77 MM)
Outer Diameter, Bottom: 3.81 IN (96.77 MM)
Inner Diameter, Top:
Inner Diameter, Bottom:
Length: 5.72 IN (145.29 MM)
Thread: 1-12
Physical Specifications
Handle: NONE
Seal Material: BUNA-N
Type of Adhesive: PLASTISOL
Type of Endcap: PLATED STEEL
Center Tube: PLATED STEEL
Type of Media: PAPER
Filter Area: SQ.IN.
Plating: ELECTROTIN PLATED
Outer Jacket: YES - METAL
Configuration: SINGLE OPEN END
Packaging Specifications
Number per Carton: 12
Carton Weight: 15.00 LB (6.80 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
