LFF3347 | Luber-Finer | Spin-On Element | OFS # 97-25-0692

SPIN-ON ELEMENT Spin-On Element Usually Ships In 24-48 Hours

Performance Data
Micron Rating:  0.00

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  20 PSID

Dimensional Specifications
Outer Diameter, Top:  3.68 IN   (93.47 MM)

Outer Diameter, Bottom:  3.68 IN   (93.47 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length:  6.94 IN   (176.28 MM)

Thread:  1-14 UNS-2B

Physical Specifications
Handle:  NONE

Seal Material:  BUNA-N

Type of Adhesive:

Type of Endcap:  PLATED STEEL

Center Tube:  STEEL

Type of Media:  PAPER

Filter Area:  SQ.IN.

Plating:  ELECTROTIN PLATED

Outer Jacket:  YES

Configuration:  SINGLE OPEN SPIN ON

Packaging Specifications
Number per Carton:  12

Carton Weight:  16.50 LB   (7.48 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
