C33445 | Mp Filtri | Spin-On Element | OFS # 97-25-0653
Performance Data
Micron Rating: 10.00 NOMINAL
Beta Rating: N/A
Collapse Pressure Rating:
Maximum Temperature: 175 F
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Additional Notes: REPLACES VOLVO (61724) PART NUMBER 834337-8
Dimensional Specifications
Outer Diameter, Top: 3.00 IN (76.20 MM)
Outer Diameter, Bottom: 3.00 IN (76.20 MM)
Inner Diameter, Top:
Inner Diameter, Bottom:
Length: 3.40 IN (86.36 MM)
Thread: 3/4"- 16 UNF
Physical Specifications
Handle: NONE
Seal Material: BUNA-N
Type of Adhesive: PLASTISOL
Type of Endcap: STEEL
Center Tube: PLATED STEEL
Type of Media: PAPER
Filter Area: SQ.IN.
Plating: ELECTROTIN PLATED
Outer Jacket: YES
Configuration: SINGLE OPEN END
Packaging Specifications
Number per Carton: 1
Carton Weight: 9.00 LB (4.08 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
