MR2503A03A | Mp Filtri | Pleated Microglass Element | OFS # 97-28-0074

PLEATED MICROGLASS ELEMENT Usually Ships In 24-48 Hours

Performance Data
Micron Rating:  3.00

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  20 PSID

Dimensional Specifications
Outer Diameter, Top:  4.13 IN   (104.90 MM)

Outer Diameter, Bottom:  4.13 IN   (104.90 MM)

Inner Diameter, Top:  2.83 IN   (71.88 MM)

Inner Diameter, Bottom:  0.40 IN   (10.16 MM)

Length:  10.13 IN   (257.30 MM)

Thread:  NONE

Physical Specifications
Handle:  NONE

Seal Material:  BUNA-N

Type of Adhesive:

Type of Endcap:  PLATED STEEL

Center Tube:  STEEL

Type of Media:  MICROGLASS

Filter Area:  SQ.IN.

Plating:

Outer Jacket:  NONE

Configuration:

Packaging Specifications
Number per Carton:  1

Carton Weight:  6.00 LB   (2.72 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
