| Available Accessories |
Horizontal Drain Kit 5000 Psig (Jdk5000H), Vertical Drain Kit 5000 Psig (Jdk5000V), Differential Pressure Gauge And Bracket (Bdpi-25) |
| Bowl Material |
Steel |
| Brand |
Finite |
| Coating Option |
Epoxy Powder Paint |
| Drain Port Size |
SAE-6 |
| Materials : Head |
Spheroidal Graphic Cast Iron |
| Maximum Operating Pressure (Bar) |
345 |
| Maximum Operating Pressure (Psig) |
5000 |
| Maximum Operating Temperature (C) |
175 |
| Maximum Operating Temperature (F) |
350 |
| Plating |
Nickel Plated |
| Replacement Element |
J Series Filter Replacement Elements |
| Seal Material |
Fluorocarbon |
| Weight (Kg) |
4.1-30.4 Depending On Configuration |
| Weight (Lbs) |
9.0-67.0 Depending On Configuration |
| Filter Type |
Water Separator |
| Micron Rating |
100 (MM) |
| Filter Rating |
99% + |
| Maximum Flow CFM |
17490 At 500 PSI |
| Thread Type |
NPT |
| Port Connection Inches |
1 1/2 |
| Parker/Singapore Product Is Only Available Upon Request |
|
