L824 | Purflux | Fuel Filter Element | OFS # 97-28-0060

FUEL FILTER ELEMENT Usually Ships In 24-48 Hours

Performance Data
Micron Rating: 12.00

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID

Dimensional Specifications
Outer Diameter, Top: 3.95 IN (100.33 MM)

Outer Diameter, Bottom: 3.95 IN (100.33 MM)

Inner Diameter, Top: 1.08 IN (27.43 MM)

Inner Diameter, Bottom: 1.08 IN (27.43 MM)

Length: 5.95 IN (151.13 MM)

Thread: NONE

Physical Specifications
Handle: NONE

Seal Material:

Type of Adhesive:

Type of Endcap: PLATED STEEL

Center Tube: STEEL

Type of Media: PAPER

Filter Area: SQ.IN.

Plating:

Outer Jacket: YES

Configuration: DOUBLE OPEN END

Packaging Specifications
Number per Carton: 1

Carton Weight: 7.30 LB (3.31 KG)
