LS842 | Purflux | Spin-On Element | OFS # 97-25-0319
Performance Data
Micron Rating: 25.00
Beta Rating: N/A
Collapse Pressure Rating:
Maximum Temperature:
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Dimensional Specifications
Outer Diameter, Top: 4.57 IN (116.08 MM)
Outer Diameter, Bottom: 4.57 IN (116.08 MM)
Inner Diameter, Top:
Inner Diameter, Bottom:
Length: 9.81 IN (249.17 MM)
Thread: 1-3/8-16UNS2B
Physical Specifications
Handle: NONE
Seal Material: BUNA-N
Type of Adhesive: PLASTISOL
Type of Endcap: PLATED STEEL
Center Tube: STEEL
Type of Media: PAPER
Filter Area: SQ.IN.
Plating: ELECTROTIN PLATED
Outer Jacket: YES
Configuration: SINGLE OPEN END
Packaging Specifications
Number per Carton: 6
Carton Weight: 20.10 LB (9.12 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
