51864 | WIX | Spin-On Hydraulic Filter
View All Applications For WIX 51864
Packaging Specifications
Number per Carton: 6
Carton Weight: 18.00 LB (8.16 KG)
Lead Time: USUALLY SHIPS IN 24-48 HOURS
Shipping Service: UPS GROUND
Performance Data
Micron Rating: 3.00 NOMINAL
Beta Rating: N/A
Collapse Pressure Rating: 100 PSID
Maximum Temperature: 250 F
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Dimensional Specifications
Outer Diameter, Top: 5.06 IN (128.52 MM)
Outer Diameter, Bottom: 5.06 IN (128.52 MM)
Inner Diameter, Top:
Inner Diameter, Bottom:
Length: 11.00 IN (279.40 MM)
Thread Size: 1 1/2"-16
Physical Specifications
Handle: NONE
Seal Material: BUNA-N
Type of Filter: SPIN-ON HYDRAULIC FILTER
Type of Adhesive: EPOXY
Type of Endcap: PLATED STEEL
Center Tube: PLATED STEEL
Type of Media: ENHANCED CELLULOSE
Filter Area: SQ.IN.
Plating: ELECTROTIN PLATED
Outer Jacket: YES - METAL
Configuration: SINGLE OPEN END
UPC Number: 765809518643
**All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacturer parts, Names and part # used for cross reference only.**
