CSP1030 | Yamashin | Spin-On Element
***Image may vary***

CSP1030 | Yamashin | Spin-On Element | OFS # 97-25-0658

  • $142.99


2 week lead time

Performance Data
Micron Rating: 10.00

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID



Dimensional Specifications
Outer Diameter, Top: 5.28 IN (134.11 MM)

Outer Diameter, Bottom:

Inner Diameter, Top:

Inner Diameter, Bottom:

Length: 6.89 IN (175.01 MM)

Thread: M48 X P2.0



Physical Specifications
Handle: NONE

Seal Material:

Type of Adhesive: PLASTISOL

Type of Endcap: PLATED STEEL

Center Tube: STEEL

Type of Media:

Type of Filter: SPIN-ON ELEMENT

Filter Area: SQ.IN.

Plating: ELECTROTIN PLATED

Outer Jacket: YES

Configuration: SINGLE OPEN SPIN ON



Packaging Specifications
Number per Carton: 1

Carton Weight: 4.00 LB (1.81 KG)



**All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
