MIN. ORDER 3

Usually Ships In 24-48 hours

Army-Navy Hydraulic Element

MIN QTY FOR ORDER : 4 UNITS

Performance Data
Micron Rating: 10.00 NOMINAL

Beta Rating: N. .

Collapse Pressure Rating: 150 PSID

Maximum Temperature: 275 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID

Additional Notes: THIS UNIT IS DESIGNED IN ACCORDANCE WITH AN6235-3A.

Dimensional Specifications
Outer Diameter, Top: 1.70 IN (43.18 MM)

Outer Diameter, Bottom: 1.70 IN (43.18 MM)

Inner Diameter, Top: 0.88 IN (22.35 MM)

Inner Diameter, Bottom:

Length: 3.40 IN (86.36 MM)

Thread: NONE

Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive: EPOXY

Type of Endcap: ALUMINUM

Center Tube: SS SPRING

Type of Media: PAPER

Filter Area: 96 SQ.IN.

Plating: NONE

Outer Jacket: NONE - NONE

Configuration: SINGLE OPEN END

Packaging Specifications
Number per Carton: 1

Carton Weight: 2.00 LB (0.91 KG)

P551755 Donaldson Cross
