P177014 | Zinga Industries | Spin-On Element With Drain | OFS # 97-28-0783
Performance Data
Micron Rating: 15.00 NOMINAL
Beta Rating: N/A
Collapse Pressure Rating:
Maximum Temperature:
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Dimensional Specifications
Outer Diameter, Top: 3.02 IN (76.71 MM)
Outer Diameter, Bottom:
Inner Diameter, Top:
Inner Diameter, Bottom:
Length: 5.63 IN (143.00 MM)
Thread: M16X1.5-6H
Physical Specifications
Handle: NONE
Seal Material: BUNA-N
Type of Adhesive: PLASTISOL
Type of Endcap: PLATED STEEL
Center Tube: STEEL
Type of Media: PAPER
Filter Area: SQ.IN.
Plating:
Outer Jacket: YES - METAL
Configuration: SINGLE OPEN SPIN ON
Packaging Specifications
Number per Carton: 12
Carton Weight: 12.00 LB (5.44 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
