0085MA025P | HYCON/HYDAC | Spin-on Filter Element
***Image may vary***

HYCON/HYDAC | 0085MA025P | Spin-on Filter Element | OFS # 97-25-0133

Spin-On Filter Element

AVAILABILITY - Usually ships in 24-48 hours

Performance Data
Micron Rating: 25.00 NOMINAL

Beta Rating: N/A

Collapse Pressure Rating: 100 PSID

Maximum Temperature: 225 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID



Dimensional Specifications
Outer Diameter, Top: 3.75 IN (95.25 MM)

Outer Diameter, Bottom: 3.75 IN (95.25 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length: 8.09 IN (205.49 MM)

Thread: 1"-12 UNF



Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive: PLASTISOL

Type of Endcap: PLATED STEEL

Center Tube: PLATED STEEL

Type of Media: PAPER

Filter Area: 601.7 SQ.IN.

Plating: ELECTROTIN PLATED

Outer Jacket: YES - METAL

Configuration: SINGLE OPEN/SPIN ON



Packaging Specifications
Number per Carton: 1

Carton Weight: 16.10 LB (7.30 KG)

**All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
