78-23545-0115 | Briggs & Stratton | OFS # 97-01-3446
Performance Data
Micron Rating: 20.00 NOMINAL
Beta Rating: N/A
Collapse Pressure Rating:
Maximum Temperature: 225 F
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Dimensional Specifications
Outer Diameter, Top: 3.15 IN (80.01 MM)
Outer Diameter, Bottom:
Inner Diameter, Top:
Inner Diameter, Bottom:
Length: 2.40 IN (60.96 MM)
Thread: 3/4-16 UNF2B
Physical Specifications
Handle: NONE
Seal Material: BUNA-N
Type of Adhesive: PLASTISOL
Type of Endcap: PLATED STEEL
Center Tube: PLATED STEEL
Type of Media: PAPER
Filter Area: SQ.IN.
Plating:
Outer Jacket: YES - METAL
Configuration: SINGLE OPEN END
Type of Filter: SPIN-ON ELEMENT
Packaging Specifications
Number per Carton: 1
Carton Weight: 8.00 LB (3.63 KG)
Cross References
- Ac Delco AC207
- Alco Locomotive MD256
- Alco Locomotive MD265
- American Motors 8983501080
- American Parts 92185
- AP Lockheed LK1090
- Atlas LF-167
- Autopart FE250
- Autopart FOE035
- Autopart FOE055
- Baldwin B7165
- Big A 92065
- Big A 92185
- Bosch 9450732006
- Bosch 9457281270
- Briggs & Stratton 695396
- Briggs & Stratton 696854
- Briggs & Stratton 842921
- Briggs & Stratton 78-23545-0115
- Carcare OF-7073
- Carcare OF7079
- Carquest 85065
- Carquest 85185
- Champ LC114
- Champ LS114
- Champion C108
- Champion C158
- Champion PH2812A
- Champion PH2814
- Champion X120
- Citroen MLS000169
- Clean DO277
- Clean DO878
- Clean ML488
- Coopers G853
- Delphi FX0016
- Delphi FX0108
- Delphi FX0133
- Deutsch D408
- Diamond FD8247
- Diamond FD8249
- Diexa DX101US
- Digoma DGM03241
- Digoma DGMO3241
- Donaldson P502024
- Fiaam FA5155
- Fiat 7683815
- Filt FF436EC
- Filter-Mart Corp 01-3446
- Filtron OM518
- Filtron OM523
- Filtron OP518
- FleetGuard LF3826
- Fleetrite LFR83826
- Ford A700X63714DA
- Ford A740X6714CA
- Ford A760X6714EA
- FRAM CH2874
- FRAM CH5151
- FRAM CH7073
- FRAM PH2814
- FRAM PH2874
- FRAM PH4806
- G.U.D. G1014
- General Motors 7984550
- Giesse CLH3461
- Giesse CLH405
- Gif-Filter GL269
- Gif-Filter LI957
- GKN Masterparts MOF22X
- GKN Masterparts MOF26X
- Greyfriars 913S
- Greyfriars 944S
- Guiot GH2830
- Guiot GH2874
- Hako 72146
- Halfords HOF236
- Hastings LF167
- Hengst D24E88.28
- Hengst E8828
- Hengst E88HD24
- Hengst H11W01
- Hengst H12W03
- Jiffy Lube HL7073
- Knecht OC24
- Knecht OX91
- Knecht OX91D
- Kralinator L651
- Lautrette ELH4044
- Lautrette ELH4073
- Lautrette ELH4082
- Lautrette ELH4090
- Lautrette ELH4163
- Lautrette ELHA4044
- Lautrette ELHA4073
- Lautrette ELHA4082
- Luber-Finer LFP2814
- Lucas 6464
- Lucas EDL116
- MAHLE OC11
- MAHLE OC24
- MAHLE OX91
- MAHLE OX91D
- MANN & HUMMEL H921/X
- MANN & HUMMEL HU921X
- MANN & HUMMEL W77
- Mapco Auto Indus 61045
- Micro Filter MH352
- Micro Filter MH356
- Micro Filter MO68
- Mighty L14758
- Mighty M833
- Mobil MA101US
- Motorcraft EFL049
- Motorcraft EFL098
- Motorcraft EFL114
- Motorcraft EFL115
- Motorcraft EFL382
- Motorcraft EFL98
- Motrio 8671000205
- NAPA 1065
- NAPA 1185
- NAPA 7035
- Online Filter Supply 97-01-3446
- Original Equipment OF-825
- PBR AC3318
- Permatic GL269
- Phoenix NH-921X
- Purflux L857
- Purflux LS169B
- Purolator FC603
- Purolator L14758
- Purolator L17603
- Purolator L17801
- Purolator L17810
- Purolator MF67100A
- Renault 7700542523
- Renault 7701033837
- Renault 7701218107
- Renault 7701348018
- Robert Bosch 72172
- Savara 92198617
- Savara 92813111
- Savara 92813117
- Separation Tech. LF3826
- Service Champ CF-4758
- Snapper 78-23545-0111
- Soparis CV354
- Soparis CV386
- Soparis OC11
- Soparis OC24
- Soparis OX91
- Soparis OX91D
- T.J. FB5300
- T.J. FP9767
- Tecafilters 9350614
- Tecalemit FB5300
- Technocar OP210
- Tecneco OL277
- Teho D205
- Teho OK48
- Teho OK72
- Unipart GFE210
- Unipart GFE211
- United Filters LE880
- United Filters LI759
- United Filters LI9581
- Valvoline LC833
- Volvo 834337
- Volvo Penta 834337
- Wako LO502
- Wipac CA104
- WIX 51065
- WIX 51185
- WIX 57035
- WIX 85432
- WIX 351P
- WIX WL7042
- WIX WL7064
- WIX WL7079
**All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
