85040MP | CARQUEST | Spin-On Filter Element
Shipping & Packaging Specifications
Number Per Carton: 12 (Individual Filters Available)
Carton Weight: 8.00 LB (3.63 KG)
Stock Status: In Stock
Lead Time: Usually Ships In 24-48 Hours
Shipping Service: UPS Ground
Performance Data
Micron Rating: 20.00 NOMINAL
Beta Rating: N/A
Collapse Pressure Rating:
Maximum Temperature: 225 F
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Dimensional Specifications
Outer Diameter, Top: 3.00 IN (76.20 MM)
Outer Diameter, Bottom: 3.00 IN (76.20 MM)
Inner Diameter, Top:
Inner Diameter, Bottom:
Length: 3.50 IN (88.90 MM)
Thread: M18 X 1.5
Physical Specifications
Handle: NONE
Seal Material: BUNA-N
Type of Adhesive: PLASTISOL
Type of Endcap: PLATED STEEL
Center Tube: PLATED STEEL
Type of Media: PAPER
Filter Area: SQ.IN.
Plating:
Outer Jacket: YES - METAL
Configuration: SINGLE OPEN END
**All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacturer parts, Names and part # used for cross reference only.**
