92281 | Big A | Hydraulic Filter Element | OFS # 97-15-2206
Performance Data
Micron Rating: 23.00
Beta Rating:
Collapse Pressure Rating:
Maximum Temperature:
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Dimensional Specifications
Outer Diameter, Top: 3.10 IN (78.74 MM)
Outer Diameter, Bottom: 3.10 IN (78.74 MM)
Inner Diameter, Top: 1.74 IN (44.20 MM)
Inner Diameter, Bottom:
Length: 8.00 IN (203.20 MM)
Thread: NONE
Physical Specifications
Handle: NONE
Filter Style: CARTRIDGE
Type of Adhesive:
Type of Endcap: PLATED STEEL
Center Tube:
Type of Media: CELLULOSE
Filter Area: SQ.IN.
Plating:
Outer Jacket: YES
Configuration: SINGLE OPEN END
Packaging Specifications
Number per Carton: 1
Carton Weight: 1.40 LB (0.64 KG)
|
COMPETITOR NAME
|
COMPETITOR PART #
|
|---|---|
| BIG A | 92281 |
| CARQUEST | 85281 |
| DONALDSON | P162955 |
| FLEETGUARD | HF6447 |
| FLEETRITE | HFR-86447 |
| HASTINGS | HF804 |
| NAPA | 1281 |
| WIX | 51281 |
**All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
