A110G10 | Filtrec | OFS # 97-25-0678

Spin-On Filter Element

Usually Ships In 24-48 Hours

Performance Data
Micron Rating: 10.00 ABSOLUTE

Beta Rating: B10=200

Collapse Pressure Rating: 58 PSI

Maximum Temperature: 212 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID

Dimensional Specifications
Outer Diameter, Top: 3.78 IN (96.01 MM)

Outer Diameter, Bottom: 3.78 IN (96.01 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length: 5.83 IN (148.08 MM)

Thread: 3/4-14BSP

Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive: EPOXY

Type of Endcap: STEEL

Center Tube: STEEL

Type of Media: MICROGLASS

Filter Area: 322 SQ.IN.

Plating: ELECTROTIN PLATED

Outer Jacket: YES

Configuration: SINGLE OPEN END

Packaging Specifications
Number per Carton: 1

Carton Weight: **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
