LFH8412 | Luber-Finer | Spin-On Element | OFS # 97-25-0655

SPIN-ON ELEMENT Spin-On Element Usually Ships In 24-48 Hours

Performance Data
Micron Rating:  12.00

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  20 PSID

Dimensional Specifications
Outer Diameter, Top:  5.00 IN   (127.00 MM)

Outer Diameter, Bottom:  5.00 IN   (127.00 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length:  8.22 IN   (208.79 MM)

Thread:  1 1/2"-16

Physical Specifications
Handle:  NONE

Seal Material:  BUNA-N

Type of Adhesive:  EPOXY

Type of Endcap:  PLATED STEEL

Center Tube:  STEEL

Type of Media:  MICROGLASS

Filter Area:  SQ.IN.

Plating:  ELECTROTIN PLATED

Outer Jacket:  YES

Configuration:  SINGLE OPEN END

Packaging Specifications
Number per Carton:  1

Carton Weight:  4.00 LB   (1.81 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
