LFP2248 | Luber-Finer | OFS # 97-25-0423
Usually Ships In 24-48 Hours
Performance Data
Micron Rating: 25.00
Beta Rating: N/A BPV 36.26
Collapse Pressure Rating:
Maximum Temperature:
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Dimensional Specifications
Outer Diameter, Top: 5.38 IN (136.65 MM)
Outer Diameter, Bottom: 5.38 IN (136.65 MM)
Inner Diameter, Top:
Inner Diameter, Bottom:
Length: 12.43 IN (315.72 MM)
Thread: 1 1/2-16
Physical Specifications
Handle: NONE
Seal Material:
Type of Adhesive: PLASTISOL
Type of Endcap: PLATED STEEL
Center Tube: STEEL
Type of Media: PAPER
Filter Area: SQ.IN.
Plating: ELECTROTIN PLATED
Outer Jacket: YES
Configuration: SINGLE OPEN SPIN-ON
Packaging Specifications
Number per Carton: 1
Carton Weight: 25.70 LB (11.66 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
