LAF2749 | Luber-Finer | Spin-On Element | OFS # 97-28-8979
Performance Data
Micron Rating: 1.00 NOMINAL
Beta Rating: B1 = 200
Collapse Pressure Rating: 100 PSID
Maximum Temperature: 225 F
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Dimensional Specifications
Outer Diameter, Top: 3.72 IN (94.49 MM)
Outer Diameter, Bottom: 3.72 IN (94.49 MM)
Inner Diameter, Top:
Inner Diameter, Bottom:
Length: 9.43 IN (239.52 MM)
Thread: 1-14 UNS-2B
Physical Specifications
Handle: NONE
Seal Material: BUA-N
Type of Adhesive: PLASTISOL
Type of Endcap: PLATED STEEL
Center Tube: PLATED STEEL
Type of Media: MICROGLASS
Filter Area: SQ.IN.
Plating: ELECTROTIN PLATED
Outer Jacket: YES - METAL
Configuration: SINGLE OPEN SPIN ON
Packaging Specifications
Number per Carton: 12
Carton Weight: 24.00 LB (10.89 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
