0-451-202-055 | Bosch | Spin-On Cellulose Filter

OFS # 97-28-0568

Performance Data

Micron Rating:  25.00 NOMINAL

Beta Rating:  N/A

Collapse Pressure Rating:  75 PSID

Maximum Temperature:  225 F

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  20 PSID

Dimensional Specifications

Outer Diameter, Top:  3.31 IN   (84.07 MM)

Outer Diameter, Bottom:  3.31 IN   (84.07 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length:  4.02 IN   (102.11 MM)

Thread:  3/4-16 UNF-2B

Physical Specifications

Handle:  NONE

Seal Material:  BUNA-N

Type of Adhesive:  PLASTISOL

Type of Endcap:  PLATED STEEL

Center Tube:  PLATED STEEL

Type of Media:  PAPER

Filter Area:  SQ.IN.

Plating:  ELECTROTIN PLATED

Outer Jacket:  YES - METAL

Configuration:  SINGLE OPEN END

Packaging Specifications

Number per Carton:  12

Carton Weight:  9.80 LB   (4.45 KG)

***All Online Filter Supply replacement parts are equivalent to or interchangeable with original manufacture parts, Names and part # used for cross reference only.***
