FS1006 | FLEETGUARD | Spin-On Element With Drain | OFS # 97-25-0767

Performance Data
Micron Rating:  15.00 NOMINAL

Beta Rating:  N/A

Collapse Pressure Rating:  75 PSID

Maximum Temperature:  225 F

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  20 PSID

Dimensional Specifications
Outer Diameter, Top:  4.74 IN   (120.40 MM)

Outer Diameter, Bottom:  4.74 IN   (120.40 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length:  12.32 IN   (312.93 MM)

Thread:  1 1/4-12 UNS2

Physical Specifications
Handle:  NONE

Seal Material:  BUNA-N

Type of Adhesive:  PLASTISOL

Type of Endcap:  PLATED STEEL

Center Tube:  PLATED STEEL

Type of Media:  PAPER

Filter Area:  SQ.IN.

Plating:  ELECTROTIN PLATED

Outer Jacket:  YES - METAL

Configuration:  SINGLE OPEN SPIN ON

Packaging Specifications
Number per Carton:  6

Carton Weight:  19.00 LB   (8.62 KG)
